General
No power source is required. It is ideal for the horizontal handling of non-porous sheet and plate material such as diamond-sawn or polished granite, engineered stone, all types of metals, plastics, and fiberglass. An automatic self-cycling valve at the piston’s bottom controls the vacuum grip-and-release cycle.
Features
- Self-powered and self-cycling.
- A non-rechargeable 9V battery powers the audio alarm system.
- Use the vacuum gauge for a visual warning of low vacuum.
- Aluminum construction.
- Telescopic front handle.
- Lightweight.
Specifications
|
Metric
|
Imperial
|
|
| Number of pad | 1 pcs | – |
| Pad diameter | Seal to seal: 450 mm | 17.7″ |
| Working load limit | 650 kg | 1433 lb |
| Net weight | 36 kg | 79 lb |
| Gross weight | 64 kg | 141 lb |
| Packaging dimensions | L.1020xW.560xH.900 mm | 40”x22”x35.4″ |
- Battery information
| Power supply | 9 V non-rechargeable |
| 6-month warranty |
Note: For materials with a rough surface texture, such as exfoliated granite, concrete, and textured metals, refer to our electric or air-powered vacuum lifters with foam rubber pads.
