General
No power source is required. Ideal for the horizontal handling of non-porous sheet and plate materials such as diamond-sawn, polished granite, engineered stone, all types of metals, plastics, and fiberglass. It has a telescopic front handlebar and adjustable vacuum pads.
Features
- Self-powered and self-cycling.
- Simple to operate.
- Easy to maintain.
- Able to handle a variety of sheet sizes.
- Extremely safe. The load cannot be released until it is set down on the surface.
- Capable of 100% duty cycle, 24 hours/day operation.
- A non-rechargeable 9V battery powers the audio alarm system.
- Use the vacuum gauge for a visual warning of low vacuum.
- Telescopic front handle.
Specifications
|
Metric
|
Imperial
|
|
| Number of pad | 1 | – |
| Pad diameter | Seal to seal: 530 mm | 21″ |
| Working load limit | 1000 kg | 2204 lb |
| Net weight | 55 kg | 121 lb |
| Gross weight | 67 kg | 148 lb |
| Packaging dimensions | L.730xW.385xH.760 mm | 28.7″x15.1″x30″ |
- Battery information
| Power supply | 9 V non-rechargeable |
| 6-month warranty | – |
Note: For materials with a rough surface texture, such as exfoliated granite, concrete, and textured metals, refer to our electric or air-powered vacuum lifters with foam rubber pads.
