General
No power source is required. It is ideal for the horizontal handling of non-porous sheet and plate material such as diamond-sawn or polished granite, polished engineered stone, and all types of metals, plastics, and fiberglass. An automatic self-cycling valve at the piston’s bottom controls the vacuum grip-and-release cycle.
Features
- Self-powered and self-cycling
- Audio alarm system powered by a non-rechargeable 9v battery
- Vacuum gauge for a visual warning of low vacuum
- Telescopic front handle
Specifications
|
Metric
|
Imperial
|
|
| Number of pad | 8 | – |
| Pad diameter | Seal to seal: 190 mm | 7.5″ |
| Working load limit | 600 kg | 1323 lb |
| Net weight | 74 kg | 163 lb |
| Gross weight | 122 kg | 269 lb |
| Packaging dimensions | L.2270xW.490xH.890 mm | 89.4″x19.3″x35″ |
- Battery information for the alarm system
| Power supply | 9V non-rechargeable |
Note: For materials with a rough surface texture, such as exfoliated granite, concrete, and textured metals, refer to our electric or air-powered vacuum lifters with foam rubber pads.
