General
As a crate extraction unit, the Slab Bundle Handler is a crane attachment used for lifting crated marble and granite slabs from closed-top containers. Designed to lift stone slab bundles securely and to increase efficiency and worker safety with improved load handling. With the addition of a Slab Bundle Handler, your existing crane can be used to perform many of the functions generally associated with a forklift truck. It is used most efficiently on gantry cranes with a 5-ton capacity or greater. The Slab Bundle Handler can also be used on mobile cranes.
Specifications
|
Metric
|
Imperial
|
|
| Working load limit | 5000 kg | 11023 lb |
| Net weight | 3200 kg | 7055 lb |
| Gross weight | 3210 kg | 7077 lb |
| Packaging dimensions | L.5780xW.630xH.1600(A) mm L.2530xW.610xH.600(B) mm |
227.5″x24.8″x62.9″ 99.6″x24″x23.6″ |
