General
Aardwolf offers a new version of its patented Aardwolf Slab Lifters. The new Aardwolf Slab Lifter Automatic AL30A has an integrated auto-lock and unlock mechanism (patent pending), which allows the clamp to automatically grip slabs on pick-up and release the slabs on set-down. This makes moving and handling slabs safer and more convenient in many situations.
Features
- Size: Being of compact construction, the Aardwolf Slab Lifter Automatic AL30A allows for close-packed stone slabs to be lifted from racks and containers. Lower-height slabs placed alongside taller slabs offer no problem, as is the case with scissor clamps.
- Versatile: Ideal for construction work. Because the clamping mechanism is to the front of the slab, they allow panels to be placed close against walls.
- Safety: Requires only a small movement of the slab to engage and grip it, which is generally well below the over-balance angle, thus eliminating the danger to the operator.
- Secure: The Aardwolf clamps grip marble and granite slabs firmly. This Aardwolf Slab Lifter Automatic has a force-multiplying factor of approximately 2.5 to 1.
Specifications
|
Metric
|
Imperial
|
|
| Grip range | 0 – 30 mm | 0 – 1″ |
| Working load limit | 1200 kg | 2646 lb |
| Net weight | 16.6 kg | 36.6 lb |
| Gross weight | 17.2 kg | 38 lb |
| Packaging dimensions | L.365xW.160xH.240 mm | 14.4″x6.3″x9.4″ |
